Jacket Control Valve

Jacket Control Valve

Valve Type:                                                 Jacket control valve


Valve Nominal Size:                                  DN20 through DN200; 0.75 inch through 8 inch


Pressure Rating:                                         PN16, 40, 63, 100; ANSI Class 150, 300, 600


Body Style:                                                  Double top stem guided or caged guided jacket


Trim Type:                                                   Unbalanced plug or balanced plug


Flow Direction:                                           Flow over the plug; Flow under the plug


Flow Characteristic:                                   Equal percentage EQ%; Linear; Quick open


Rangeability:                                               50:1


Temperature Range:                                 From -196°C to 650°C


Seat Leakage:                                             ANSI IV or V


Actuator:                                                     Pneumatic cylinder actuator; Pneumatic diaphragm actuator;

                                         Electric actuator; Hand-wheel manual for option

Description & Features

Jacket Control Valve


Jacket control valve has a straight body and designed for heat preservation by steam circulates to prevent medium from crystallization and solidification.
